img{max-width:100%} Digital Multimeter AC DC Voltmeter Ammeter Ohmmeter Volt Tester Meter XL830L USAProduct Details:This digital multimeter has all the functions you will need for electronics testing and electrical work. A wide range of functions cover just about every use case.Tests: AC Voltage, DC Voltage, Current, Resistance, Continuity, Diode, TransistorContinuity test has an auditory buzzer, Data hold button locks displayed value, Back-light button illuminates the displayProbes DC Voltage Modes:200mV (100µV resolution)2V (1mV resolution)20V (10mV resolution)200V (100mV resolution)600V (1V resolution)DC Current Modes:200µA (0.1µA resolution)2mA (1µA resolution)20mA (10µA resolution)200mA (100µA resolution)10A (10mA resolution)AC Voltage Modes:200V (100mV resolution)600V (1V resolution)Continuity Test:If continuity exists a built in buzzer will soundDiode Test:Show the approximate forward voltage drop of the diodeResistance Test:200Ω (0.1Ω resolution)2kΩ (1Ω resolution)20kΩ (10Ω resolution)200kΩ (100Ω resolution)2mΩ (1kΩ resolution)Transistor hFE Test:NPN & PNP 0-1000 3V 10µAAdditional Features:Data hold button locks displayed valueBack-light button illuminates the displayKickstand9V Battery - Not IncludedPackage Includes:MultimeterProbe CablesInstruction Manual Extra Information: Bring back the original brand new look!This is a NEW part.This item is BRAND NEW!Save MONEY and your Device using the best replacement part available.This Assembly ships with a protective foam wrap, along with a protective plastic to prevent any scratches.This item is very carefully packagedPayment Information:We Accept PayPalWe Accept Credit Card via PayPalShipping Information: We provide Same Day FREE SHIPPING domestically within the U.S.A USPS First Class (3-5 business days) & USPS First-Class International (14 days with tracking)(We do ship to APO/FPO)We reserve the right to charge additional shipping fee for reship items due to wrong shipping address provided during checkout.All orders before 5PM EST will ship out same day!, Monday - FridayShips Same Day Today! Refund & Return Policy:We offer a 30 day return policy on all items purchased from us.Please contact us within 30 days after receipt of the item for a return.Do not ship the item back to us without contacting us first.Return shipping is responsibility of buyer.-We thank you so much for looking! If you have any questions or concerns, please do not hesitate to message us. Have a great day!p.p1 {margin: 0.0px 0.0px 2.0px 0.0px; font: 14.0px 'Helvetica Neue'}p.p2 {margin: 0.0px 0.0px 0.0px 0.0px; font: 12.0px 'Helvetica Neue'}{margin: 0.0px 0.0px 0.0px 0.0px; font: 12.0px 'Helvetica Neue'}span.s1 {text-decoration: underline}span.s2 {font: 10.0px Menlo}{list-style-type: disc}
